35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134

35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134

35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134

MOQ:	10
harga:	1

Detail Information

Product Description

Detail Information

Sertifikasi:

ISO9001

Model No.:

Y5wz5-51/134

Jenis instalasi:

Penangkap Paralel

Tegangan Operasi:

Tegangan tinggi

Membentuk:

Spiral

Bahan:

Zno

Media pemadam busur api:

Udara

Bahan perumahan:

Porselen

Tegangan sistem:

35kv

Tegangan sistem nominal:

35

Tegangan Dinilai:

51

Tegangan operasi terus menerus:

40.8

Tegangan referensi minimum:

73

Impuls arus tinggi:

65

Kelas pelepasan saluran:

1

Berat:

55 kg

Menyoroti:

35kV porcelain lightning arrester

,

ZnO substation arrester Y5WZ5-51/134

,

high voltage lightning arrester with warranty

Product Description

35kV Porcelain Housed Gapless Metal Oxide Lightning Arrester (Y5WZ5-51/134)

Product Specifications

Attribute	Value
Model NO.	Y5WZ5-51/134
Installation	Parallel Arrester
Application	Substation
Size	Large
Operation Voltage	High Voltage
Shape	Spiral
Material	ZnO
Arc-Extinguishing Medium	Air
Housing	Porcelain
Accessories	Surge Counter
System Voltage	35kV
Transport Package	by Wood Carton
Specification	SGS
Trademark	YongDe
Origin	China
HS Code	85354000
Production Capacity	100PCS/Month

Product Images

35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134 0

35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134 1

35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134 2

35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134 3

35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134 4

35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134 5

Key Features

Double sealing structure with core encapsulated by molded silicone rubber for complete sealing solution
Two-way pressure release structure for enhanced safety
ZnO varistor core component with excellent pressure ratio consistency, large flow capacity, and high reliability
Wide creepage distance suitable for III level heavy pollution areas

Technical Specifications

Type	Nominal System Voltage	Rated Voltage	Continuous Operating Voltage	MRV under 1/5 μs Steep Discharge Current	MRV under 8/20 μs Lightning Discharge Current	MRV under 30/60 μs Operating Discharge Current	Minimum Reference Voltage under 1 mA DC	4/10 μs High Current Impulse Twice (KA)	2mS SW through-flow capacity A/18	Line Discharge Class	Weight kg
Y5WZ5-51/134	35	51	40.8	154		134		114		73	65	150 400	1	55

MRV means Maximum Residual Voltage

35kV Porcelain Housed ZnO Lightning Arrester Y5WZ5-51/134 6
